Description
PW24100-S | Specifications |
---|---|
Cell Type | LiFePO4 |
Nominal Voltage | 25.6V |
Battery Capacity | 105Ah |
Nominal Energy | 2.688kWh |
Dimension [L x W x H] | 420 x 400 x 133 mm 16.5 x 15.7 x 5.2 in |
Weight | 25kg 55 lbs |
Working Voltage | 20V~29.2V |
Charge Voltage | 29.2V |
Discharge Cut-off Voltage | 20V |
Maximum Charge Current | 100A Continuous |
Maximum Discharge Current | 100A Continuous |
Fast Charging 快速充电 | Supports Fast Charging 支持快速充电 |
Charging Temperature 充电温度 | 0~60°C 32℉~140℉ |
Discharging Temperature | -20~60°C -4℉~140℉ |
Operating Humidity Range | <30% |
Series / Parallel Number | 8S1P |
Max. Parallel Connection | 16p to 43kWh |
Cycle Life (25°C / 77℉@60% DOD) | >8000 Cycles |
Cycle Life (25°C / 77℉@80% DOD) | >6000 Cycles |
Self-Discharge Rate | <3% per month |
IP Grade | IP21 / (More request) |
Battery Case | Steel |
Monitoring & Protection | Smart BMS: Overcharge / OverDischarge / Overcurrent / OverTemperature / ShortCircuit |
Communication | RS485 / CAN-bus |
Optional Functions | Bluetooth / WiFi / Circuit Breaker / Heating / Active Balance / LED Touch Screen / APP |
Accessories | Inverter Power Cable, Parallel Cable, Communication Cable, Grounding Wire |
Compatible Inverters | Victron / GOODWE / Solis / Growatt / SMA / SAJ / Luxpower / SRNE / Deye / Voltronic, etc. |
Color | White / Gray / Black |
Design Life | 20 Years |
Warranty | 10 Years |
User Manual | With the Battery Packaging |
Certification & Safety Standard | UN38.3 / MSDS / (More request) |
