Lithium Battery Selection Guide
JOINSUN OEM Lithium Battery Factory
Empower your business with reliable lithium energy for golf carts, e-scooters, forklifts, and more. Choose versatile 12V to 72V batteries to drive farther, ride longer, and maximize efficiency with robust, long-lasting lithium power.
21700 Lithium Cell Battery
Empower your business with reliable lithium energy.
Rack-mounted Lithium Battery
Empower your business with reliable lithium energy.
Golf Cart / Sightseeing Car
Drive farther with long-lasting lithium performance.
12V~72V Lithium Batteries
Versatile power solutions from 12V to 72V lithium.
E-Scooter / E-Bike / E-Rickshaw
Ride longer, charge faster with advanced lithium power.
Electric Forklift / AMR / AGV
Maximize efficiency with robust lithium power for every lift.
Rack-mounted Lithium Battery
Joinsun’s rack-mounted lithium solutions offer reliable, space-efficient energy storage for your business. Ideal for maximizing power in confined spaces, these batteries provide versatile 48V and higher options, ensuring robust performance and long-lasting efficiency in various applications.
Model
basic
Rated Energy
Max Charge
Terminal
Size / Weight
48V 100Ah
3U
LiFePO4 48V 100Ah
4.8 kWh
100 A
M6
440×440×136 mm
39 kg
48V 100Ah 3U PRO
LiFePO4 48V 100Ah
4.8 kWh
100 A
Single Core Quick Plug ESS Connector
440×440×136 mm
39 kg
51.2V 100Ah
3U
LiFePO4 51.2V 100Ah
5.12 kWh
100 A
M6
440×440×136 mm
42 kg
51.2V 100Ah
3U PRO
LiFePO4 51.2V 100Ah
5.12 kWh
100 A
Single Core Quick Plug ESS Connector
440×440×136 mm
42 kg
48V 50Ah
3U
LiFePO4 48V 50Ah
2.4 kWh
50 A
M6
440×440×136 mm
23 kg
48V 50Ah 2U PRO
LiFePO4 48V 50Ah
2.4 kWh
50 A
Single Core Quick Plug ESS Connector
410x440x88.5 mm
21 kg
51.2V 50Ah
3U
LiFePO4 51.2V 50Ah
2.56 kWh
50 A
M6
440×440×136 mm
24 kg
51.2V 50Ah 2U PRO
LiFePO4 51.2V 50Ah
2.56 kWh
50 A
Single Core Quick Plug ESS Connector
410x440x88.5 mm
23 kg
Telecom SNMP 48V 100Ah 3U
LiFePO4 48V 100Ah
48 kWh
100 A
M6
440×440×136 mm
39 kg
Telecom SNMP 51.2V 100Ah 3U
LiFePO4 51.2V 100Ah
5.12 kWh
100 A
M6
440×440×136 mm
41 kg
Telecom SNMP 48V 150Ah 4U
LiFePO4 48V 150Ah
7.2 kWh
100 A
M6
550×440×136 mm
51 kg
Telecom SNMP 51.2V 150Ah 4U
LiFePO4 51.2V 150Ah
7.68 kWh
100 A
M6
550×440×136 mm
53 kg
48V 200Ah 5U
LiFePO4 48V 200Ah
9.6 kWh
100 A
M6
570 x 440 x 230mm
85 kg
24V 100Ah 3U
LiFePO4 25.6V 100Ah
2.56 kWh
100 A
M6
440×440×136 mm
23 kg
Golf Cart, Club Car, Sightseeing Car, LSV Lithium Battery
Joinsun offers reliable lithium power for golf carts, club cars, sightseeing vehicles, and LSVs. Available in 36V, 48V, 60V, 72V, and higher, our batteries ensure extended range, faster charging, and exceptional performance for every ride.
Model
basic
Rated Energy
Max Charge
Peak Discharge
Size /
Weight
36V 50Ah
LiFePO4 38.4V 56Ah
2.15 kWh
50 A
200 A (10s)
385×338×245 mm
60 lb (27 kg)
36V 80Ah
LiFePO4 38.4V 80Ah
3.07 kWh
80 A
200 A (10s)
385×338×245 mm
68 lb (31 kg)
36V 100Ah
LiFePO4 38.4V 105Ah
4.03 kWh
100 A
200 A (10s)
385×338×245 mm
75 lb (34 kg)
36V 100Ah (LCD)
LiFePO4 38.4V 100Ah
3.84 kWh
100 A
200 A (10s)
400x315x155 mm
32 kg
48V 50Ah
LiFePO4 51.2V 56Ah
2.86 kWh
50 A
200 A (10s)
500x355x247mm
73 lb (33 kg)
48V 100Ah
LiFePO4 51.2V 105Ah
5.37 kWh
230 A
250 A (10s)
500x355x247mm
95 lb (43 kg)
48V 100Ah
LiFePO4 51.2V 105Ah
5.37 kWh
100 A
200 A (10s)
500x355x247mm
103 lb (46.8 kg)
48V 100Ah
LiFePO4 51.2V 105Ah
5.37 kWh
150 A
315 A (30s)
565×330×255 mm
103 lb (46.8 kg)
48V 120Ah
LiFePO4 48V 125Ah
6 kWh
100 A
200 A (10s)
520x275x232 mm
104 lb (47 kg)
48V 150Ah
LiFePO4 48V 150Ah
7.2 kWh
200 A
400 A (10s)
510x410x235 mm
121 lb (55 kg)
48V 160Ah
LiFePO4 51.2V 160Ah
8.19 kWh
100 A
200 A (30s)
800×332×332 mm
159 lb (72 kg)
48V 160Ah
LiFePO4 51.2V 160Ah
8.19 kWh
160 A
315 A (30s)
800×332×332 mm
165 lb (75 kg)
48V 200Ah
LiFePO4 51.2V 200Ah
10.24kwh
180A
200 A (30s)
750x330x273 mm
174 lb (79 kg)
48V 200Ah
LiFePO4 51.2V 200Ah
10.24kwh
200A
200 A (30s)
940x340x250 mm
198 lb(90 kg)
72V 100Ah
LiFePO4 76.8V 105Ah
8.06 kWh
100 A
315 A (30s)
740×320×246 mm
159 lb (72 kg)
72V 160Ah
LiFePO4 76.8V 160Ah
12.28 kWh
160 A
315 A (30s)
960x446x217 mm
194 lb (88 kg)
72V 180Ah (LCD)
LiFePO4 76.8V 180Ah
13.82 kWh
180 A
360 A (10s)
718x370x270 mm
123kg
72V 200Ah
LiFePO4 76.8V 200Ah
15.36 kWh
200 A
315 A (30s)
1138x410x253 mm
276 lb (125 kg)
72V 200Ah(LCD)
LiFePO4 76.8V 200Ah
15.36 kWh
200 A
400 A (10s)
718x370x270 mm
126kg
96V 100Ah
LiFePO4 96V 100Ah
9.6 kWh
100 A / 250 A
300 A (10s)
950x295x290 mm
198 lb (90 kg)
12V~72V Lithium Batteries
Joinsun provides versatile lithium solutions from 12V to 72V, catering to various applications. Whether for RVs, e-scooters, or industrial use, our batteries deliver reliable, long-lasting power, ensuring optimal performance and efficiency across a wide range of voltages.
12V
Model
basic
Rated Energy
Max Charge
Peak Discharge
Size /
Weight
12V 6Ah
LFP 12.8V 6Ah
76.8 Wh
6A / 10A
18 A (5s)
151x65x95mm
0.7kg
12V 20Ah
LFP 12.8V 20Ah
256 Wh
20A / 30A
60 A (5s)
177x167x124mm
2kg
12V 30Ah
LFP 12.8V 30Ah
384 Wh
30A
90 A (5s)
195x130x161mm
3kg
12V 50Ah
LFP 12.8V 50Ah
640 Wh
50A
150 A (5s)
198x166x170mm
5kg
12V 75Ah
LFP 12.8V 75Ah
960 Wh
75A
225 A (5s)
260x168x210mm
Group 24 / 6kg
12V 90Ah
LFP 12.8V 90Ah
11.52 kWh
90A
270 A (5s)
306x168x211mm
Group 27 / 7kg
12V 100Ah
LFP 12.8V 100Ah
1.28 kWh
100A
300 A (5s)
260x168x210mm
Group 24 / 9kg
12V 100Ah EU
LFP 12.8V 100Ah
1.28 kWh
100A
300 A (5s)
395x110x286mm
9kg
12V 120Ah
LFP 12.8V 120Ah
1.536 kWh
100A
360 A (5s)
330x172x215mm
Group 31 / 10kg
12V 120Ah EU
LFP 12.8V 120Ah
1.536 kWh
100A
360 A (5s)
552x110x240mm
10kg
12V 150Ah
LFP 12.8V 150Ah
1.92 kWh
100A
450 A (5s)
330x172x215mm
Group 31 / 14kg
12V 150Ah
LFP 12.8V 150Ah
1.92 kWh
100A
120 A (10s)
331x175x222mm
Group 31 / 14.3kg
12V 150Ah EU
LFP 12.8V 150Ah
1.92 kWh
100A
450 A (5s)
552x110x288mm
13kg
12V 180Ah
LFP 12.8V 180Ah
2.3 kWh
100A
500 A (5s)
501x185x242mm
16kg
12V 180Ah EU
LFP 12.8V 180Ah
2.3 kWh
100A
500 A (5s)
580x132x242mm
15kg
12V 200Ah
LFP 12.8V 200Ah
2.56 kWh
100A
500 A (5s)
501x185x242mm
18kg
12V 250Ah
LFP 12.8V 250Ah
3.2 kWh
200A
500 A (5s)
522x240x218mm
21kg
12V 300Ah
LFP 12.8V 300Ah
3.84 kWh
200A
500 A (5s)
523x269x218mm
Group 8D / 26kg
12V 400Ah
LFP 12.8V 400Ah
5.12 kWh
200A
500 A (5s)
522x240x218mm
37kg
12V 500Ah
LFP 12.8V 500Ah
6.4 kWh
300A
500 A (5s)
524x220x467 mm
68kg
24V
Model
basic
Rated Energy
Max Charge
Peak Discharge
Size /
Weight
24V 50Ah
LFP 25.6V 50Ah
1280 Wh
50A
100A (3s)
260x168x210 mm
Group 24 / 10kg
24V 60Ah
LFP 25.6V 60Ah
1536 Wh
50A
100A (3s)
330x172x215 mm
Group 31 / 11kg
24V 80Ah
LFP 25.6V 80Ah
2048 Wh
50A
100A (3s)
255x205x195 mm
16kg
24V 100Ah
LFP 25.6V 100Ah
2560 Wh
100A
200A (3s)
501x185x242 mm
18kg
24V 105Ah
LFP 25.6V 105Ah
2688 Wh
100A
200A (3s)
522x240x218 mm
19kg
24V 100Ah EU
LFP 25.6V 100Ah
2560 Wh
100A
200A (3s)
552x110x288 mm
19kg
24V 100Ah
LFP 25.6V 100Ah
2560 Wh
30A / 100A
200A (3s)
295x220x310 mm
30kg
24V 150Ah
LFP 25.6V 150Ah
3840 Wh
100A
200A (3s)
523x269x218 mm
Group 8D / 25kg
24V 180Ah
LFP 25.6V 184Ah
4710 Wh
100A
200A (3s)
678x238x158 mm
35kg
24V 200Ah
LFP 25.6V 200Ah
5120 Wh
100A
200A (3s)
523x269x218 mm
Group 8D / 40kg
24V 300Ah
LFP 25.6V 300Ah
7680 Wh
200A
300A (3s)
522x240x218 mm
45kg
36V，48V，60V，72V
Model
basic
Rated Energy
Max Charge
Peak Discharge
Size /
Weight
36V 60Ah
LiFePO4 38.4V 60Ah
2304 Wh
50A
501x185x24 mm
15kg
36V 100Ah
LiFePO4 25.6V 105Ah
4032 Wh
100A
200A (10S)
520x267x227 mm
33kg
36V 120Ah
LiFePO4 38.4V 120Ah
4608 Wh
60A
640x245x220 mm
36kg
48V 50Ah
LiFePO4 51.2V 50Ah
2560 Wh
50A
501x185x242 mm
20kg
48V 60Ah
LiFePO4 51.2V 60Ah
3072 Wh
50A
523x269x218 mm
Group 8D / 22kg
48V 100Ah
LiFePO4 51.2V 100Ah
5120 Wh
100A
523x269x218 mm
Group 8D / 39kg
48V 100Ah
LiFePO4 51.2V 105Ah
5376 Wh
100A
610x290x185 mm
43kg
60V 20Ah
LiFePO4 60.8V 20Ah
1216 Wh
20A
60A (5S)
330x172x237 mm
10kg
60V 30Ah
LiFePO4 60.8V 30Ah
1824 Wh
30A
90A (5S)
330x172x237 mm
15kg
60V 50Ah
LiFePO4 60.8V 50Ah
3040 Wh
50A
150A (5S)
522x269x220 mm
24kg
72V 50Ah
LiFePO4 73.6V 50Ah
3680 Wh
50A
150A (5S)
522x269x220 mm
29kg
Electric Scooter, Rickshaw, Trishaw, eBike, Motorcycle
Joinsun powers electric scooters, rickshaws, trishaws, eBikes, and motorcycles with advanced lithium technology. Our batteries ensure longer rides, quicker charges, and reliable performance, offering versatile solutions for 36V, 48V, 60V, and higher to meet diverse needs.
Model
basic
Rated Energy
Max Charge
Peak Discharge
Size /
Weight
48V 20Ah (GPS)
LiFePO4 48V 20Ah
960Wh
20A
60 A (5s)
155x140x250 mm
6 kg
48V 200Ah
48V 200Ah
9.6 kWh
100 A / 200 A
400 A (10s)
650x400x270 mm
85 kg
60V 20Ah (LCD)
NCM 61.2V 20Ah
1.22 kWh
20 A
80 A (3s)
179x153x239 mm
60V 20Ah
NCM 61.2V 20Ah
1.22 kWh
20 A
60 A (5s)
380x53x207 mm
12kg
60V 30Ah
NCM 61.2V 30Ah
1.83 kWh
30 A
90 A (5s)
380x53x207 mm
15kg
60V 40Ah (GPS)
NCM 61.2V 40Ah
2.45 kWh
20 A / 40 A
80 A (5s)
220x160x295 mm
60V 100Ah (LCD)
LiFePO4 60.8V 100Ah
6.08 kWh
100 A
200 A (3s)
208x115x92 mm
45kg
60V 150Ah
LiFePO4 60.8V 150Ah
9.12 kWh
100 A
200 A (3s)
(Customized)
60V 200Ah(LCD)
LiFePO4 60.8V 200Ah
12.16 kWh
100 A / 150 A
300 A (3s)
997x598x181 mm
153 kg
72V 20Ah
LiFePO4 72V 20Ah
1.44 kWh
20 A
60 A (5s)
180x154x300 mm
9.8kg
72V 27Ah (LCD)
NCM 72V 27Ah
1.944 kWh
15A / 30A
60 A (10s)
210x85x41 mm
10kg
72V 30Ah (LCD)
NCM 72V 26.4Ah
1.9 kWh
15 A / 30 A
60 A (10s)
380x210x75 mm
11 kg
72V 40Ah
NCM 72V 40Ah
2.88 kWh
20 A / 60 A
80 A (5s)
410x180x150 mm
16 kg
Electric Forklift, AGV, AMR, RGV, LGV, E-Pallet Truck, Towing Tractor Truck, Walkie Pallet Jack
Joinsun powers electric forklifts, AGVs, AMRs, e-pallet trucks, and towing tractors with robust lithium solutions. Our batteries ensure efficient operation, longer runtimes, and quick charging, providing reliable 48V and higher options for demanding industrial applications.
Model
basic
Rated Energy
Max Charge
Terminal
Size / Weight
24V 50Ah
LiFePO4 25.6V 50Ah
1.28 kWh
40 A
100 A (3s)
250x165x118 mm
8.5 kg
24V 160Ah
LiFePO4 25.6V 160Ah
4.1 kWh
160 A
480 A (30s)
623x209x626 mm
90 kg
24V 200Ah
LiFePO4 25.6V 202Ah
5.1 kWh
100 A
600 A (30s)
645x195x570 mm
160 kg
24V 210Ah
LiFePO4 25.6V 210Ah
5.3 kWh
150 A
800 A (5s)
630x251x450 mm
60 kg
24V 280Ah
LiFePO4 25.6V 280Ah
7.1 kWh
200 A
800 A (5s)
630x251x450 mm
63 kg
24V 560Ah
LiFePO4 25.6V 560Ah
14.3 kWh
350 A
500 A (30s)
778x324x570 mm
385 kg
36V 240Ah
LiFePO4 38.4V 240Ah
9.2 kWh
120 A
720 A (3s)
870x400x430 mm
250 kg
36V 690Ah
LiFePO4 38.4V 690Ah
26.5 kWh
320 A
480 A (5s)
967x515x779 mm
330 kg
72V 300Ah
LiFePO4 76.8V 300Ah
23 kWh
150A
300 (5s)
800x550x400 mm
245 kg
80V 420Ah
LiFePO4 80V 420Ah
33.6 kWh
320 A
450 A (5s)
937x797x777 mm
409 kg
80V 420Ah
LiFePO4 83.2V 420Ah
35 kWh
200 A
1000 A (5s)
950x592x450 mm
280 kg
Model
basic
Rated Energy
Max Charge
Terminal
Size / Weight
48V 210Ah
LiFePO4 51.2V 210Ah
10.7 kWh
210 A
420 A (30s)
949x374x550 mm
200 kg
48V 300Ah
LiFePO4 51.2V 304Ah
15.5 kWh
150 A
600 A (5s)
940x260x520 mm
164 kg
48V 420Ah
LiFePO4 51.2V 420Ah
21.5 kWh
200 A
1000 A (5s)
950x421x450 mm
190 kg
48V 420Ah
LiFePO4 51.2V 420Ah
21.5 kWh
350 A
500 A (30s)
949x349x569 mm
300 kg
48V 450Ah
LiFePO4 51.2V 456Ah
23.3 kWh
0.5C
3C (30s)
815x740x450 mm
750 kg
48V 460Ah
LiFePO4 51.2V 460Ah
23.5 kWh
200 A
900 A (3s)
830x630x590 mm
339 kg
48V 460Ah
LiFePO4 51.2V 460Ah
23.5 kWh
200 A
900 A (3s)
820x660x470 mm
600 kg
48V 460Ah
LiFePO4 51.2V 460Ah
23.5 kWh
200 A
1000 A (5s)
950*421*450 mm
190 kg
48V 460Ah
LiFePO4 51.2V 460Ah
23.5 kWh
200 A
900 A (3s)
800x630x600 mm
352 kg
48V 500Ah
LiFePO4 51.2V 500Ah
24 kWh
300 A
900 A (5s)
645x196x573 mm
260 kg
48V 560Ah
LiFePO4 51.2V 560Ah
28.6 kWh
250 A
1000 A (3s)
810x630x600 mm
352 kg
48V 560Ah
LiFePO4 51.2V 560Ah
28.6 kWh
200 A
1000 A (5s)
950x592x450 mm
210 kg
48V 600Ah
LiFePO4 51.2V 608Ah
31 kWh
300 A
1200 A (3s)
800x630x600 mm
352 kg
48V 630Ah
LiFePO4 51.2V 630Ah
32.2 kWh
200 A
1000 A (5s)
950x592x450 mm
228 kg
Efficient Power Solutions to Meet Your Needs
JOINSUN offers reliable power equipment to help optimize energy usage and reduce costs. Whether for industrial or commercial projects, we provide customized solutions based on your specific requirements. Contact us today to learn more and get a quote.
